Description
Specifications
1. All Around
- Carrier frequency: 200-599MHZ
- Frequency stabilization: <+20ppm
- Dynamic Range: more than 80dB
- T.H.D at 1KHz: less than 0.5%
- Frequency response: 40Hz-18Hz+3dB
- Audio output level: 0~±400nV
- mix out 0~±200mV
- Temperature range: 10°C to 50°C
- Manipulate range: radio 200
2. Fixed Receiver
- Power supply: AC 200V/50Hz
- Consume Power: 3 water
- Signal/noise ratio: >80dB
- Image & Spurious rejection: 70dB
- Border upon channel rejection: >70dB
- S/N: less than 12dBu(sind=20dB)
- De-emphasis: 50 us
