Description
| Frequency Response | All inputs: 20 Hz – 22 kHz (±1 dB) |
| THD+N (Total Harmonic Distortion) | All inputs: < 0.005% (@ 4 dBu, 1 kHz) |
| Gain Range | Mic inputs (Channels 1-2): 0 – 50 dB
Line inputs (Channels 1-2): 15 dBu – 35 dBu Line inputs (Channels 3-6): -20 dBu – +20 dBu |
| Max Voltage Gain | 70 dB (MIC INPUT to MAIN MIX OUTPUT)
80 dB (MIC INPUT to CTRL ROOM / PHONES OUPTUT) 60 dB (MIC INPUT to MON SEND) |
| SNR (Signal-to-Noise ratio) | All inputs: > 110 dBu |
| Crossover Frequency | Adjacent inputs: < -80 dB @ 1 kHz
Inputs to outputs: < -75 dB @ 1 kHz (stereo L/R, Channels 1-2, panned hard left or right) |
| Phantom Power | +45 ~ +49V with switch control |
| Impedance | Mic inputs: 3.9 kΩ
All other inputs: > 10 kΩ Aux outputs: 1 kΩ All outputs: 120 Ω |
| Equalization | High: ±15 dB @ 12 kHz
Low: ±15 dB @ 80 Hz |
| Bluetooth | Profile: A2DP
Module: Bluetooth 5.0 Operating Frequency: 2402 MHz – 2480 MHz Range: 100 ft. / 30.5 m |
| Connectors | (6) 1/4” (6.35 mm) TRS outputs
(6) 1/4” (6.35 mm) TRS stereo L/R inputs (4) 1/4″ (6.35 mm) TRS headphone outputs (4) 1/4″ (6.35 mm) TRS mono inputs (1) Standard RCA L/R input (1) Standard RCA L/R output (4) XLR inputs (1) USB type-B input (1) DC power input |
| Controls | (1) Power switch
(15) volume control knobs (1 per input, 1 return, 1 EFX return, 1 2-track/USB in, 4 headphone outs, 1 Bluetooth, 1 main) (6) Stereo pan control knobs (1 per input) (6) Mon volume control knobs (1 per input) (6) EQ Low control knobs (1 per input) (6) EQ Hi control knobs (1 per input) (6) Gain control knobs (1 per input) (4) Buttons (1-EFX mute, 1 Bluetooth, 2 Source Select) (1) Horizontal sliding switch |
| Indicators | (1) Power LED
(6) Peak LEDs (1) Phantom LED (16) Main Out Meter LEDs (1) Bluetooth LED |
| Power | Connection: DC
Voltage: 18V, 1.2A Consumption: 18W |
| Dimensions
(width x depth x height) |
2.0” x 9.4” x 3.1”
305 x 238.5 x 79 mm |
| Weight | 4.5 lbs.
2.04 kg |
