Description
System Specifications
Carrier Frequency Range: 610–960 MHz
Bandwidth: 50 MHz
Modulation Mode: FM
Maximum Frequency Deviation: ±45 kHz
Frequency Response: 80 Hz – 15 kHz
Signal-to-Noise Ratio: >50 dB (A-Weighted)
Total Harmonic Distortion (THD): <2% @ 1 kHz
Operating Temperature: -10°C to +55°C
Power Consumption: 3 W
Receiver Specifications
Oscillation Mode: PLL (Digital Frequency Synthesizer)
Carrier Frequency Range: 610–960 MHz
Bandwidth: 50 MHz
Pilot Tone: Pilot + Digital ID
Modulation Mode: FM
Frequency Stability: <30 ppm
Sensitivity: 5 dBμV
Image Rejection: >80 dB
Spurious Rejection: >80 dB
Balanced Audio Output: 250 mV / 600 Ω (XLR)
Unbalanced Audio Output: 400 mV / 3.2 kΩ (6.35 mm)
Operating Voltage: DC 12–16 V
Current Consumption: <500 mA
Handheld Transmitter Specifications
Oscillation Mode: PLL (Digital Frequency Synthesizer)
RF Output Power: Up to 30 mW
Carrier Frequency Stability: <30 ppm
Dynamic Range: >100 dB (A)
Frequency Response: 50 Hz – 15 kHz
Maximum SPL: 130 dB SPL
Microphone Type: Dynamic (Moving Coil)
Power Supply: 2 × AA Alkaline Batteries
Product guidance and quotation
Compare this model with other wireless microphone systems. Confirm current availability and the exact specifications required for your system. Contact CentroPro with your intended application and connection requirements for a product quotation.
