Description
Receiver Specifications
Oscillation: PLL Synthesized
Carrier Frequency Range: UHF 500–590 MHz
Frequency Stability: ±0.001%
Modulation Mode: FM
Signal-to-Noise Ratio: >105 dB
Total Harmonic Distortion (THD): <0.5% @ 1 kHz
Sensitivity: 1.2 μV @ 12 dB S/N
Power Supply: DC 12–15 V
Audio Output:
• Independent Output: 0–400 mV
• Mixed Output: 0–300 mV
Transmitter Specifications
Power Supply: 3 V DC (2 × AA 1.5 V Batteries)
Current Consumption: 100 mA
Carrier Frequency Range: UHF 500–590 MHz
Frequency Stability: ±0.005%
Maximum Deviation: ±30 kHz
Signal-to-Noise Ratio: >60 dB
Adjacent Channel Rejection: >80 dB
Dynamic Range: ≥100 dB
Microphone Type: Condenser
Polar Pattern: Unidirectional
Frequency Response: 40 Hz – 20 kHz
Sensitivity: -43 ±3 dB @ 1 kHz
