RCF ART 912AX - Professional Active Bluetooth® Speaker

Frequency Response: 50 Hz – 20000 Hz

Max SPL @ 1m: 130 dB

Horizontal coverage angle: 100°

Vertical coverage angle: 60°

Compression Driver: 1 x 1.0”, 1.75” v.c

Woofer: 12”, 2.5” v.c

Input connectors: Combo XLR/Jack

Output connectors: XLR

Crossover Frequencies: 1600Hz

Protections: Thermal, RMS

Limiter: Soft Limiter

Controls: Color touch panel, data entry/volume encoder, dedicated App for iOS and Android.

Total Power: 2100 W Peak

High frequencies: 700 W Peak

Low frequencies: 1400 W Peak

Cooling: Convection

Connections: VDE

Frequency Response: 20 Hz – 20 Hz

THD+N, 20dB gain, 0dBu out: 0.005% A-Weighted

Processing Channels: 6

Signal Processing: 24 Bit

A/D-D/A conversion: 32 Bit @ 48.0 kHz

Dynamic range: 110

Remote Controlled Storable Gain: Yes

Gain Range: 0 dB – 42 dB

Input Noise Level: -114 dBu A-Weighted

Mic Inputs Impedance: 6 kΩ

Low Cut: 20 Hz – 400 Hz

Phantom Power +48V: Yes

Mono Line: 2

Gain Selection: 0 dB – 22 dB

Line Input Impedance: 21 kΩ

A/D Dynamic range: 114 dB

Stereo Line: 1

Gain Selection: 0 dB – 10 dB

Stereo Line Input Impedance (kOhm): 13 kohm

Main MIX: 1

Main Out Impedance: 150 ohm

Main Out Level: 22 dBu

D/A Dynamic Range: 114 dB

RCF Compressors: Compressors on Mic/Line CH1 & CH2 inputs.

Input Channels EQ: 2 Shelving 1

Description:
– 3 Band EQ: High and Low band shelving, MID band peak on IN
– 5 Band EQ: 4 Full Parametric, 1 High Shelving and HPF 24 dB/Oct on Amplifier and MAIN output,

Send Effects: 1

Main OUT type: Mix Out, Crossover Out With Rcf Subwoofers Presets, Stereo Output, Ch1 Link Out.

Safety agency: CE compliant

Cabinet/Case Material: PP Composite

Hardware: 1 x M10 top, 1 x M10 each side

Handles: 1 top, 1 each side

Pole mount/Cap: 35 mm insert

Grille: Steel

Color: Black

Height: 642 mm / 25.28 inches

Width: 370 mm / 14.57 inches

Depth: 363 mm / 14.29 inches

Weight: 18.7 kg / 41.23 lbs
