Description
Key Specifications
Usable Bandwidth (-10 dB): 66 Hz – 20 kHz
Maximum SPL: 140 dB
Nominal Directivity (-6 dB)
- Enclosure: 10°
- Panflex™ Horizontal Coverage:
- 70° Symmetric
- 110° Symmetric
- 90° Asymmetric
Transducers
- LF: 1 × 10-inch cone driver
- HF: 1 × 2.5-inch diaphragm compression driver
Acoustic Design
- LF: Bass-reflex with L-Vents
- HF: DOSC waveguide with Panflex™ technology
Nominal Impedance: 8 Ω
Connectors: 2 × 4-point SpeakON
Physical Specifications
Cabinet: Premium-grade Baltic beech and birch plywood
Front Grille
- Coated steel grille
- Acoustically transparent 3D fabric
Rigging Components: High-grade steel with anti-corrosion coating
Rigging & Handling
- Flush-fitting 2-point rigging system
- 2 integrated handles
- 8 corner stops
- 2 ground runners
- 1 × DIN580-compatible M8 threaded insert
Physical Specifications
- Dimensions (W × H × D): 581 × 350 × 367 mm
- Weight: 22 kg (49 lb)
Finish
- Dark Grey Brown (Pantone 426 C)
Environmental Rating
- IP55 weather protection
Applications
- Live sound reinforcement
- Touring productions
- Houses of worship
- Theatres and performing arts venues
- Corporate events
- Auditoriums
- Fixed installations requiring precise medium-throw coverage
