Description
Acoustical specifications
Frequency Response (-10 dB): 100 Hz – 20000 Hz
Max SPL @ 1m: 98 dB
Coverage angle: 150°
System Sensitivity: 90 dB
Power section
Amplification: Full Range
Power Handling: 6 W
Peak Power Handling: 24 W Peak
Recommended Amplifiers: DMA 504, DMA 162, DMA 82, DMA 162P, ES 2160, ES 3080, AM 2320, AM 2160, AM 2080, AM 1125, UP 8504, UP 8502, UP 8501, UP 2321, UP 2162
Transducers
Fullrange: 1 x 6.0”
Input/Output section
Input connectors: Screw Terminals
Output connectors: Screw Terminals
Constant Voltage Transformer: 100 V
Power Selection 1: 6 W – 1667 ohm
Power Selection 2: 3 W – 3333 ohm
Standard compliance
Safety agency: CE compliant
Physical specifications
Cabinet/Case Material: Plastic
Hardware: Metal
Grille: Plastic
Color: White – RAL 9003
Size / Weight
Depth: 65 mm / 2.56 inches
Recessed Depth: 59 mm / 2.32 inches
Diameter: 186 mm / 7.32 inches
Weight: 0.5 kg / 1.1 lbs
