Description
Specifications
Operating Voltage: AC 90–220 V, 50/60 Hz
Light Source: OSRAM SIRIUS HRI 330 W or YODN R17 350 W Lamp (8000 K)
Power Consumption: 500 W
Zoom: 0°–35°
Focus: Electronic Focus
Color Wheel: 13 Colors + Open, Bi-Directional Rotation with Variable Speed
Rotating Gobo Wheel: 12 Rotating Gobos + Open
Fixed Gobo Wheel: 16 Fixed Gobos + Open, Flow and Shake Effects with Adjustable Speed
Frost: Frost Filter with Wide Coverage and Uniform Brightness
Prism: 12-Facet Prism, Bi-Directional Rotation with Variable Speed
Dimming: 0–100% Linear Dimming
Strobe: 1–13 Flashes/sec, Mechanical Strobe with Dual Blades
Pan/Tilt Movement: Pan 540°, Tilt 280° (16-Bit Resolution) with Automatic Position Correction
Effects: Color, Gobo, Prism, and Strobe Auto Run
Cooling System: Forced Air Cooling
Control Protocol: DMX512 (3-Pin XLR)
DMX Channels: 16 CH / 22 CH
Display: LCD Touchscreen
Protection Rating: IP20
Protection Features: Overheating and Overvoltage Protection
Dimensions (L × W × H): 352 × 289 × 551 mm
Packing Dimensions (L × W × H): 405 × 370 × 635 mm
Net Weight: 16 kg
Gross Weight: 18 kg
