PR8100

Description

1. Voltages: 100/120/200/220/230/240V AC, 50/60 Hz
2. Power Consumption: 480W@220V
3. Light Source: OSRAM Diamond Dragon LED, Hi-power 5W LEDS, 90 LEDS (30 Red + 30 Green + 30 Blue)
4. Average service life: 50,000 hours
5. Colors: RGB Color mixing, 10 preset fixed colors
6. Color Temperature: 0~100% linearly adjustable from 3200K to 10000K. 4 Pre-set fixed color temperatures: 3200K, 5600K,7200K,10000K
7. Dimmer: 0~100% linearly adjustable (8- or 16-bit)
8. Strobe: 1~25 F.P.S.
9. Beam angle: Standard: 13°, Optional: 23°
10. Field angle: Standard: 26°, Optional: 46°
11. Control and Programming: DMX 512, 5-pin interface, standalone mode, Master/Slave operation and Self-testing mode, 3 pre-set programs, Programmable by user from control panel & RDM
12. Other features: Automatically turn off power when LED temperature is too high, Automatic fan speed control
13. DMX Channels: Short mode: 8, Standard mode: 13, Extended mode: 17
14. Head Movement: Pan 540°, Tilt 270° (8- or 16-bit), Automatic Pan/Tilt position correction, Adjustable Pan/Tilt Speed
15. Display: LCD, brightness and contrast adjustable, Inversion display function, Usage time display
16. Ambient temperature: -20°C~40°C
17. Housing: Composite plastic and aluminum (IP20)
18. Net weight: 11 kg
