Description
Features
- Mini desktop public address amplifier with dual-layer PCB circuit design
- 2 × Microphone inputs
- 2 × AUX inputs
- 1 × AUX output
- MIC 1 priority function
- Independent bass and treble controls
- Low impedance output: 4–8 Ω
- High impedance outputs: 70 V / 100 V
Specifications
Model: PDM-60U
Power Supply: 110–220 V AC, 50–60 Hz
Output Power: 60 W
Frequency Response: 80 Hz – 20 kHz
Total Harmonic Distortion (THD): <0.5% @ 1 kHz (100 V, -3 dB)
Speaker Output: 4–8 Ω, 70 V, 100 V
Input Sensitivity: AUX: 500 mV / 10 kΩ, MIC 1: 1–6 mV
Signal-to-Noise Ratio: 75 dB
Tone Control:
• Bass: 100 Hz ±10 dB
• Treble: 10 kHz ±10 dB
Dimensions (W × H × D): 240 × 88 × 220 mm
Weight: 3 kg
