Description
Specifications
Operating Voltage: AC 100–240 V, 50/60 Hz
Power Consumption: 243 W @ 100 V / 240 W @ 240 V
Power Factor: 0.966 PF @ 100 V / 0.938 PF @ 240 V
Input Current: 2.315 A @ 100 V / 1.06 A @ 240 V
Power Linking: Up to 4 units @ 100 V / 8 units @ 240 V
DMX Linking: Supported
LED Source: 200 W White LED
Drive Current: 13 A
Luminous Flux: 2865 lm
Luminous Efficiency: 8.40 lm/W
Dimming: 0–100%
Strobe: 0–20 Hz
Beam Angle: 35°, 45°, or 60° (Optional)
Color Wheel: 7 Colors + Open
Rotating Gobo Wheel: Yes
Fixed Gobo Wheel: Yes
Control Protocol: DMX512, RDM
DMX Channels: 6 CH / 7 CH
Operation Mode: Touchscreen
Display: OLED
Functions: Auto Run, Built-in Programs, DMX512, Master/Slave, RDM
Protection Rating: IP65
Certifications: CE, RoHS
Operating Temperature: -20°C to +45°C
Product Dimensions (L × W × H): 560 × 318 × 200 mm
Inner Carton Dimensions: 675 × 390 × 300 mm
Outer Carton Dimensions: 700 × 415 × 330 mm
Net Weight: 12 kg
Gross Weight: 13.4 kg
Product guidance and quotation
Compare this model with other LED effect lights. Confirm current availability and the exact specifications required for your application. Contact CentroPro with your venue, control and installation requirements for a product quotation.
